HIGHLY-CONCENTRIC, THIN-WALL, LARGE-DIAMETER SHAFTS

一瞥

• 专有工艺提供精密公差、薄壁轴
• Shafts as large as 42F
• 强大的内部垂直整合导管开发和制造能力

Work with the Catheter Experts^TM

At Teleflex Medical OEM, our technical expertise in thin-wall, reinforced catheter shafts is among the best in the industry. We are a global leader in terms of tubing profiles and tolerances on the inner and outer diameters of reinforced shafts. In addition, we can meet very high concentricity levels on wall thickness.

Our catheter team has the deep expertise and the integrated capabilities that allow us to successfully take on the large-diameter catheter projects others simply cannot handle. This is due to:

• Proprietary manufacturing techniques and “trade secret” knowledge developed over the 25+ years.
• Teleflex Medical OEM’s culture of incremental innovation and asking, “Why not?”
• 全面的、内部的、垂直集成的能力，包括产品概念开发、工程设计、材料选择、监管服务、可制造性设计、原型设计、制造和精加工操作。

Top Four Reasons to Partner with Us for Your Catheter Project

• 一：市场领先的能力和容忍度
  • Up to 42F braided sheath, wall thickness as thin as .008” (.2mm)
  • ID tolerances: +/-.002”
  • 外径公差：+/-.002”
• TWO: Full range of value-added capabilities
  • 非创伤性尖端部分的粘合。
  • 过度成型为导管组件增加了复杂的几何结构。
  • Proprietary process of joining shaft segments of dissimilar diameters and reinforcement.
  • Full suite of on-site color matching and compounding capabilities.
• THREE: Broad range of material and reinforcement combinations
  • Range of liner materials: (PTFE, FEP, ETFE, HDPE, Pebax^®，和聚酰胺）
  • Numerous reinforcement options and configurations, which includes:
    • Continuous coiling
    • 多丝卷绕
    • 变螺距卷绕编织
    • 纵向加强卷制和编织
• Four: Knowledge, experience and the expertise gained over 25+ years
  • Focus on design for manufacturability and performance.
  • Strong catheter testing capabilities.
  • 广泛的定制，在许多情况下，独特的解决方案。

Guide to Reinforced, Large-Diameter, Thin-Wall Shafts

Pebax^®-内衬大直径编织轴

• 从12F到42F的薄壁护套的挤压。
• Pebax^®can provide high clarity in a range of durometers, and allows ease of bonding in terms of adhesives and overmoulding.
• The material is a good base material to allow addition of a hydrocoat layer.
• Pebax^®is suitable for Gamma, EtO, and autoclave sterilization.

FEP/ETFE衬里，大直径编织轴

• Extrusion of extremely thin-walled sheaths from 12F to 42F. These wall thicknesses are as thin as can be manufactured by any means at the given diameter.
• FEP is a good low-cost alternative for applications requiring good lubricity.
• Both FEP and ETFE are made with continuous processes and therefore have a low unit cost point.
• Good lubricity and chemical resistance.
• FEP and ETFE are suitable for Gamma, E-beam, EtO, and autoclave sterilization.

HDPE衬里，大直径编织轴

• Extrusion of thin-walled sheaths from 12F to 42F.
• The material is a good, low-cost alternative for applications requiring good lubricity.
• Extruded using a continuous process and therefore low unit cost point.
• HDPE衬垫特别适用于高密度编织设计（确保非常好的层压）。
• Good lubricity and chemical resistance.
• HDPE can be used in continuous extrusion (like Pebax^®或FEP/ETFE).
• HDPE适用于伽马射线、电子束、EtO和高压灭菌器灭菌。

Customization Is What We Are All About

Teleflex Medical OEM is your single source solution for product development and manufacturing. Our extensive, vertically integrated capabilities include concept development, engineering, design for manufacturabillity, regulatory affairs, material selection and formulation, prototyping, testing and validation, manufacturing, finishing operations, assembly and packaging.
阅读更多

史诗医疗技术^®Centers: Goodbye Guesswork, Hello Success

Get your device to market fast. Develop a market-ready device. Reduce technical risk. This is device development accomplished in days…不是几周、几个月或几年。Now available: Virtual, device development services.无需旅行！我们改变了我们的想法^®过程在线协作工具s, including video conferencing. You work securely and remotely with our expert team.
